Technical Data
Energy Storage Battery for Home, Office, Power Shortage Villiage,
Isolated Island, Powerless Farm/Mine Plant, Peak Load Shifting, Factory/Park Backup, Grid Stabilization.
Suitable for areas with rich Solar, Wind power.
Key Features
All new grade A cell garranteed with high consistency and stability. Batteries are tested with 6000+ cycle life. CE certified, UN38.3 and MSDS report ready.
Meets European battery life standards with extensive on-going support, both hardware and software.
Flexible and robust connection with support up to 9-units-connection in series that offers high voltage uninterrupted power supply.
Stack installation method with firm stands, slim design fits narrow spaces.
Battery voltage also available in other styles (with different suffix in p/n).
Approvals
Downloads
Specifications
| MODEL | RM50H | RM75H | RM100H | RM140H |
|---|---|---|---|---|
| Standard Voltage | 51.2VDC | |||
| Voltage Range | 43.2 ~ 57.6VDC | |||
| Nominal Capacity | 100Ah | 150Ah | 200Ah | 280Ah |
| Rated Energy | 5.12kWh | 7.68kWh | 10.24kWh | 14.336kWh |
| Communication | CAN / RS485 / RS232 / WIFI (Optional) / Blue Tooth (Optional) | |||
| Cell Self-discharge | < 5% / Month | |||
| Modules Connection | 1 ~ 15 Batteries in Parallel | |||
| DoD | 90% | |||
| Cycle Life | 6000 cycles @ 25℃, 80% DoD | |||
| Max. Charge Current | 100A | 200A | ||
| Max. Discharge Current | 100A | 200A | ||
| Ingress Protection | IP20 | |||
| Installation Method | Rack / Wall / Rack Cabinet / Ground Stand | |||
| Working Temp. | Suggested -10 ~ 50℃ | |||
| Storage Temp. | Suggested -20 ~ 55℃ | |||
| Humidity | Suggested ≤ 80% | |||
| Product Dimension | 49 x 43 x 18cm | 78 x 52 x 18cm | 78 x 52 x 18cm | 75 x 49 x 24cm |
| Package Dimension | 55 x 51 x 30cm | 90 x 62 x 39cm | 90 x 62 x 39cm | 88 x 55 x 45cm |
| Net Weight | 41kg | 52kg | 85kg | 106kg |
